E-MTBs – a completely new off-road experience
The e-mountain bike is an exciting expansion of what cycling has to offer. Higher, faster, farther – that’s what it’s all about with E-MTBs! A mountain bike that is equipped with an electric drive does simply have more power – the mature technology includes strong motors and long-lasting rechargeable batteries which ensure a new kind of mountain biking experience.
The components do, of course, keep pace with this development to meet the special requirements of an e-mountain bike. Thanks to the central positioning of motor and battery, the riding fun on the trail does not suffer at all. On the contrary, uphill sections are now characterized by joy and speed instead of fatigue – you will experience the so-called “Uphill Flow“! ➤ Learn more about E-MTBs!Electronic accessories and special parts for your e-bike can be found here:
Electric Mountain Bike
Radon Jealous Hybrid CF 500Wh
Radon Slide Hybrid 140 8.0 500Wh
Radon ZR Team Hybrid Active 8.0 500Wh
Radon ZR Team Hybrid Active 7.0 500Wh
Radon ZR Team Hybrid 9.0 500Wh
Radon ZR Lady Hybrid Active 7.0 500Wh
Radon ZR Team Hybrid 6.0 500Wh
Cube Stereo Hybrid 140 Race 500 27.5 iridium´n´blue
Radon Slide Hybrid 140 9.0 500Wh
Radon Swoop Hybrid 8.0 500Wh
Cube Stereo Hybrid 120 Pro 500 iridium´n´red
Cube Stereo Hybrid 120 Race 500 orange´n´green
Cube Stereo Hybrid 120 Race 500 black´n´blue
Cube Stereo Hybrid 160 SL 500 KIOX 27.5 black´n´grey
Cube Stereo Hybrid 140 TM 500 KIOX 27.5 grey´n´orange
Cube Stereo Hybrid 120 HPC TM 500 KIOX grey´n´orange
Cube Access Hybrid EXC 500 blue´n´coral
Cube Reaction Hybrid ONE 500 iridium´n´white
Cube Reaction Hybrid Pro 500 Allroad black edition
Cube Reaction Hybrid EAGLE 500 black´n´blue
Cube Stereo Hybrid 160 Action Team 500 KIOX actionteam
Cube Reaction Hybrid SL 500 KIOX iridium´n´black
Cube Access Hybrid ONE 500 black´n´mint
Radon Swoop Hybrid 9.0 500Wh
Ebikes and eMTBs, also known as pedelecs (pedal electric cycle), are bicycles that are equipped with an electric motor, a control system and a rechargeable battery. The control system ensures that the engine only supports when the driver pedals. If he stops pedaling, the support also stops. Some ebikes support up to 25 km/h, others will not switch off the motor support until 45 km/h are reached. But only models with a maximum speed of 25 km/h are permitted for off-road driving and biking in the forest and on dirt or mountain roads. Faster ebikes are only permitted on public roads and thus of no real interest for ambitious MTB drivers.
There are two different drive types: medium and rear engines. Each drive has its own advantages and disadvantages, depending on the driver’s needs and way of biking. For e-mountainbikes driven in different kinds of terrain, mid engines are best suited and thus recommended. Due to the central and low position of the engine, this construction type offers the best conditions for balanced handling. On the other hand, only hub motors allow energy recovery (recuperation).
You can also choose between a hardtail MTB or a fully. A hardtail has a sprung front wheel but no rear suspension. A fully offers full suspension and thus more comfort, but weight and manufacturing costs are higher. Besides, a fully consists of more moving parts that could turn into problems.
Pedelec or ebike?
Don’t let the different names confuse you: In the early days, most companies and professionals used the (correct) term “pedelec“. Nowadays the internationally common term ebike is often also used for electric bikes or MTBs with throttle grips. These types enable motor supported driving without pedaling at all. But due to legal reasons, a precise distinction can be important.
About 90 % of the electrically assisted two-wheelers sold in the EU are pedelecs due to EU-category L1e-A. Legally, these are bicycles with a maximum speed of 25 km/h (plus tolerance) and a rated continuous motor power of 250 watts. That is why no registration, helmet or driving licence is required. Some models have a start-up aid of up to 6 km/h, so that up to this speed, the driver needs no muscle power.
All pedelecs sold in the EU require an EU declaration of conformity including CE marking. Particular attention should be paid to this when you buy an imported pedelec or want to import one yourself.
Can a normal mountainbike be equipped with an electric motor?
In general, an engine can be retrofitted to conventional mountainbikes. The battery is placed in the frame triangle instead of the bottle holder. But as a mid engine requires a specially designed frame, the recommended drive type for MTBs cannot be refitted to a normal MTB because the frame is not strong enough to cope with the forces of the retrofit engine. You also have to take into account that the warranty of the frame (or generally of the bike manufacturer) expires, and the refitting is anything but trivial. So the best idea is to buy a complete eMTB with a good engine to ensure best performance and road feel and avoid technical and legal risks.
Does an eMTB need special attachments?
Currently, no manufacturer does have to install any special parts on an e-mountainbike. However, due to the added weight stable disc brakes with large discs or strong hydraulic brakes are recommended on E-MTBs, also a torsionally stiff suspension fork and stable wheels. Safety is more important than performance, and anyway, in motor assisted biking it’s not the lightweight construction that comes first.
Bosch for EMBT engines and electronics
The more power the driver supplies, the more can the engine add. Depending on manufacturer and support mode, the motor adds between 50 and 400 percent. Of course, the question which bike or drive is best cannot be answered in general. But due to practical experience, we recommend Bosch for the electric/electronic bike parts. With Bosch, you are definitely driving the best because the market leader has been offering reliable technology for years, which is constantly being supplemented with new innovations. In addition, there will be no problems with spare parts supply here in the future.
The Bosch Performance CX engine constantly measures the pedaling force, cadence and speed to perfectly adjust the added power. Lately, Bosch has introduced a software update to increase efficiency and (off-)road feel for the Performance CX motors. Now, the Bosch motors feel even more authentic, like riding a “real” mountainbike.
