Focus JAM² SL 8.7
2.699,00 €
incl. 19% VAT
- In stock, delivery time 11-17 Days
Product information "JAM² SL 8.7"
Features - JAM² SL 8.7
- Light e-mountain bike thanks to a lightweight carbon frame and the Fazua Ride 60 e-drive with 60 Nm and 430 Wh battery
- 160 mm travel DVO Diamond e-bike suspension fork and 150 mm RockShox Deluxe rear shock with F.O.L.D. kinematics
- Fully integrated C.I.S. cable routing with trail-ready
- SRAM NX Eagle 1x12 shifting and SRAM DB8 disc brakes with 200 mm rotors
- RaceFace AR30 rims with offset and Novatec hubs
- Removable battery
Highlights
JAM² SL
The JAM² SL model range stands for a light full carbon frame that is fully optimised on low weight without compromising on usability and stability aspects. A super-compact FAZUA Ride 60 e-supportintegrated in a design that makes you reach new Highs. A fun-oriented geometry with 160/150 mm suspension that is built around a high trail agility without neglecting the bike’s stability. The motor and battery of our JAM² SL are fully integrated which ensures optimal protection of the e-drive and makes this e-MTB not just ride but also look like a pure bike. The thoughtfully engineered carbon layout creates the perfect balance of low weight and high stiffness. Additionally, great usability of the light e-MTB was crucial when designing the bike. To provide most flexibility while reducing weight, Focus evaluated all kinds of charging options. Focus decided for a removable battery that can easily be taken out of the bike on the bottom side of the down tube. As you can use the Allen key from the thru-axle of your JAM² SL to unlock the down tube cover, the only needed tool is always by your side. After opening the cover, you can easily remove the FAZUA ENERGY 430 battery with only one click.
Geometry
The new JAM² SL features an easy adjustment of the head angle between 64.5° and 65.5° by turning the headset cups. Choosing a steeper head angle results in a more agile handling of the bike, while the slack position gives it a more
downhill-oriented setting. Adjusting the handling of this light e-bike to your own preferences won't affect the seat angle or other parameters. Thanks to our FLIP CHIPs at the rear triangle, you can balance your bike's geometry according
to your riding style. The adjustment from 440 to 447 mm changes your whole set-up. When switching your FLIP CHIPs to a long position, the JAM² SL rides more stable and makes steep climbs easier. If you prefer manuals and a more agile geometry, change it to the short position and get your extra kick. Based on those two components, your JAM² SL can have four individual geometry settings with head angle slack or steep and chainstay long or short. These options also make sure that your bike geometry is well-balanced and adjusted to your size.
Sealed bearings
All frame bearings have an additional seal to increase their liftetime.
Maximum system weight
This sportive and light e-MTB is made for a total system weight (bike, rider, and equipment) of 135 kg.
Frame protection
Focus has developed custom frame protection for areas that are exposed to a higher risk of damage such as the down tube and chainstay. To protect your JAM² SL from paint damage, the accessory kit also contains custom frame stickers.
Technologies
FOCUS OPTIMIZED LINKAGE DESIGN F.O.L.D.
F.O.L.D. stands for FOCUS Optimised Linkage Design, and offers the ultimate in rear suspension. The patented F.O.L.D. kinematics make it possible to optimise the rear triangle for an extremely wide range of different requirements: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out. For JAM² SL Focus has reduced the number of joint parts of the F.O.L.D. and thus significantly saved weight. The updated kinematic design further reduces brake influences and gives you maximum control of your bike in every situation.
COCKPIT INTEGRATION SOLUTION C.I.S.
C.I.S. stands for Cockpit Integration Solution and summarizes all internal cable routing on the cockpits of our road, gravel and mountain bikes. We developed several C.I.S. stems specifically to the needs of the bike category, f.e. an aero stem for the IZALCO MAX or a super short stem for our mountain bikes. They all have in common that they route all cables through stem and headset into the frame while still providing perfect functionality for both electronic and mechanical shifting. As a result, your cockpit looks super clean and the cables are protected internally.
FLIP CHIP
Different riders have different preferences and different trails may require a different set-up. That's why we want our bike to fit your riding style and local trails! For nimble handling on playful trails, you can leave the FLIP CHIP in the "HIGH" position and it will give you plenty of agility. If you like it hard and rough and have challenging trails around the corner, set to "LOW".
- Manufacturer number: 663617032
- EAN: 4000990452465
- Model Year: 2024
Europa-Allee 26
49685 Emstek
Deutschland
https://www.focus-bikes.com/de
Focus JAM² SL 8.7
Features - JAM² SL 8.7
- Light e-mountain bike thanks to a lightweight carbon frame and the Fazua Ride 60 e-drive with 60 Nm and 430 Wh battery
- 160 mm travel DVO Diamond e-bike suspension fork and 150 mm RockShox Deluxe rear shock with F.O.L.D. kinematics
- Fully integrated C.I.S. cable routing with trail-ready
- SRAM NX Eagle 1x12 shifting and SRAM DB8 disc brakes with 200 mm rotors
- RaceFace AR30 rims with offset and Novatec hubs
- Removable battery
Highlights
JAM² SL
The JAM² SL model range stands for a light full carbon frame that is fully optimised on low weight without compromising on usability and stability aspects. A super-compact FAZUA Ride 60 e-supportintegrated in a design that makes you reach new Highs. A fun-oriented geometry with 160/150 mm suspension that is built around a high trail agility without neglecting the bike’s stability. The motor and battery of our JAM² SL are fully integrated which ensures optimal protection of the e-drive and makes this e-MTB not just ride but also look like a pure bike. The thoughtfully engineered carbon layout creates the perfect balance of low weight and high stiffness. Additionally, great usability of the light e-MTB was crucial when designing the bike. To provide most flexibility while reducing weight, Focus evaluated all kinds of charging options. Focus decided for a removable battery that can easily be taken out of the bike on the bottom side of the down tube. As you can use the Allen key from the thru-axle of your JAM² SL to unlock the down tube cover, the only needed tool is always by your side. After opening the cover, you can easily remove the FAZUA ENERGY 430 battery with only one click.
Geometry
The new JAM² SL features an easy adjustment of the head angle between 64.5° and 65.5° by turning the headset cups. Choosing a steeper head angle results in a more agile handling of the bike, while the slack position gives it a more
downhill-oriented setting. Adjusting the handling of this light e-bike to your own preferences won't affect the seat angle or other parameters. Thanks to our FLIP CHIPs at the rear triangle, you can balance your bike's geometry according
to your riding style. The adjustment from 440 to 447 mm changes your whole set-up. When switching your FLIP CHIPs to a long position, the JAM² SL rides more stable and makes steep climbs easier. If you prefer manuals and a more agile geometry, change it to the short position and get your extra kick. Based on those two components, your JAM² SL can have four individual geometry settings with head angle slack or steep and chainstay long or short. These options also make sure that your bike geometry is well-balanced and adjusted to your size.
Sealed bearings
All frame bearings have an additional seal to increase their liftetime.
Maximum system weight
This sportive and light e-MTB is made for a total system weight (bike, rider, and equipment) of 135 kg.
Frame protection
Focus has developed custom frame protection for areas that are exposed to a higher risk of damage such as the down tube and chainstay. To protect your JAM² SL from paint damage, the accessory kit also contains custom frame stickers.
Technologies
FOCUS OPTIMIZED LINKAGE DESIGN F.O.L.D.
F.O.L.D. stands for FOCUS Optimised Linkage Design, and offers the ultimate in rear suspension. The patented F.O.L.D. kinematics make it possible to optimise the rear triangle for an extremely wide range of different requirements: F.O.L.D. is extremely sensitive while being progressive enough to prevent a harsh bottom out. For JAM² SL Focus has reduced the number of joint parts of the F.O.L.D. and thus significantly saved weight. The updated kinematic design further reduces brake influences and gives you maximum control of your bike in every situation.
COCKPIT INTEGRATION SOLUTION C.I.S.
C.I.S. stands for Cockpit Integration Solution and summarizes all internal cable routing on the cockpits of our road, gravel and mountain bikes. We developed several C.I.S. stems specifically to the needs of the bike category, f.e. an aero stem for the IZALCO MAX or a super short stem for our mountain bikes. They all have in common that they route all cables through stem and headset into the frame while still providing perfect functionality for both electronic and mechanical shifting. As a result, your cockpit looks super clean and the cables are protected internally.
FLIP CHIP
Different riders have different preferences and different trails may require a different set-up. That's why we want our bike to fit your riding style and local trails! For nimble handling on playful trails, you can leave the FLIP CHIP in the "HIGH" position and it will give you plenty of agility. If you like it hard and rough and have challenging trails around the corner, set to "LOW".
- Manufacturer number: 663617032
- EAN: 4000990452465
- Model Year: 2024
Europa-Allee 26
49685 Emstek
Deutschland
https://www.focus-bikes.com/de
Configuration
| Frame: | Carbon technology frame, 150mm F.O.L.D. GEN3 kinematics, 148x12 thru axle, internal cable routing, Post Mount 180 mm |
|---|---|
| Frame material: | Carbon |
| Wheel size: | 29" |
| Speeds: | 1 x 12 |
| Colour: | Warmgrey / Carbon glossy |
| Fork: | DVO Diamond E3, 110x15 mm, 44 mm rake, 160 mm |
| Rear Shock: | Rock Shox Deluxe Select+, 210/55 mm, hardware: 25.0 x 8.0 mm, no Bushing 150 mm |
| Travel: | 160 mm / 150 mm |
| Brakes: | SRAM DB8, 4-piston |
| Brake discs: | 200 mm / 200 mm |
| Headset: | ACROS ZS56/ZS66 (ICR), FOCUS C.I.S: Integrated, 1.5/1.8" angle headset |
| Stem: | FOCUS C.I.S. integrated, 50 mm, 0°, 35 mm, aluminium |
| Handlebar: | Aluminium, 800 mm, rise: 30 mm, backsweep: 9° |
| Saddle: | fi'zi:k Taiga |
| Seatpost: | Post Moderne dropper post PM-MT171, 31.6 mm, S/M: 440mm, L/XL: 480mm |
| Crankset: | Samox EC40 ISIS, 165 mm, 32T |
| Rear derailleur: | SRAM NX Eagle, 12-speed |
|---|---|
| Gear shifters: | SRAM SX Eagle, 12-speed |
| Cassette: | Sram PG-1230 Eagle, 12-speed, 11-50T |
| Chain: | SRAM SX Eagle, 12-speed |
| Tyres: | Maxxis Minion DHF, EXO, 63-622 |
| Front hub: | Novatec D041, 15x110 mm |
| Rear hub: | Novatec D462, 12x148 mm |
| Spokes : | Niro, black |
| Rims: | RaceFace AR30 Offset |
| Display: | Fazua LED Hub + Ring Control |
| Battery: | Fazua Ride 60 Energy 430, 430 Wh, removeable |
| Engine: | Fazua Ride 60, 60 Nm, 450 W max. |
| Pedals: | MTB, with reflector |
| Maximum total weight allowed: | 135 kg (body weight + bike + equipment) |
| Weight: | 20.19 kg |
Fazua E-MTB Technology
FAZUA RIDE 60It's all about Better Rides! It fuels you up before and after work, it’s a retreat and a tool to explore, to get fit, to challenge limits – that is cycling. Across all categories: FAZUA RIDE 60 is the supreme assistance for smart commuters, adventurous gravel cyclists and demanding e-mountainbikers. Stay tuned where our adventures will take you! More powerful than ever – and yet super compact. Lightweight and quiet. The Fazua Ride 60 offers an incomparable, natural riding experience. It empowers with a high efficiency and dynamic yet is unobtrusive and guarantees an amazingly fluid pedal stroke. A strong yet exceptionally lightweight assistance in a compact design that allows an individual, aesthetic integration for a smooth, natural assistance with an incredibly intuitive handling. Weight: 4,2 kg |
DRIVE UNITThe FAZUA RIDE 60 DRIVE UNIT is the heart of the system, holding motor, gear box and sensors. It’s light and silent, powerful and compact – and guarantees FAZUA’s inherent natural, smooth pedal stroke. The slim unit allows an elegant integration into the frame. Weight: 1,96 kg |
|
|
|
ENERGY 430A perfect assembly of the right amount of cells in an aesthetic housing results in a compact battery with a great range. Within the frame, the battery sits on a special, lightweight rail. The battery starts automatically when the bike is moving. The integrated handle and intuitive latch let the battery slide safely into your hands. Depending on the bike manufacturer, the FAZUA ENERGY 430 is either removable or permanently installed. Weight: 2,30 kg |
|
|
CHARGE PORTThe ENERGY 430 can be charged via the CHARGE PORT directly in the frame. The easy-to-use, intuitive magnetic plug positions itself automatically without any fumbling – and the cap closes magnetically as well. Charging option supports up to 3A. |
|
|
FAZUA RING CONTROLThe minimalist RING CONTROL on the handlebar utilizes an incredibly intuitive design. Here you can choose the support mode, turn on the light and the walk assist – all without taking your eyes off the track. |
|
|
FAZUA LED HUBThe LED HUB with its five color LEDs informs you not only about the battery charge and your riding mode. It also features a USB-C charging option for your smartphone or GPS device, and interface for ANT+ and Bluetooth. |
|
|
FAZUA CONTROL HUBThe ergonomic CONTROL HUB fuses the functions of the LED HUB and the RING CONTROL: It sets the support mode and provides all relevant information and the ANT+, Bluetooth and USB-C interface. |
|
|
FAZUA CONNECTEDAs you like: the FAZUA App allows easy and full customization. Choose from three preset riding modes. Adjustable to empower your individual ride. BREEZE RIVER ROCKET |
Geometry
