SRAM Level Ultimate Stealth 4-piston rear disc brake TOP-DEAL
Product information "Level Ultimate Stealth 4-piston rear disc brake TOP-DEAL"
The Sram Level Ultimate Stealth combines the top Level Ultimate brake with the new Stealth housing to give you one of the lightest and slimmest brakes on the market. It has the power-to-weight ratio performance you expect from it and a new lever design that provides a clean, fast-paced cockpit.
Features - SRAM Level Ultimate Stealth 4-Piston
- Stealth design to match the AXS cockpit
- Trail-ready performance in a modern XC package, for the racing of the future
- Tool-free grip width adjustment for easy customisation
Product features
- Range of use: MTB
- Brake type: Hydraulic disc brake
- Brake calliper design: 4-piston brake calliper
- Brake pad: Steel-backed organic
- Brake caliper mount: Postmount
- Brake fluid: DOT 5.1
- Mounting: right - rear
- Pad / bracket: Mounting from above
- Ambidextrous: Yes
- Recommended brake disc: HS2 (not included in the scope of delivery!)
Cable length (choose variant)
- 1600 mm
- 1650 mm
- 1700 mm
- 1750 mm
Material
- Brake lever: Carbon
- Brake lever housing: Aluminium
- Brake caliper: Aluminium
Colour
- silver
Scope of delivery
- 1 SRAM Level Ultimate Carbon rear disc brakes (no box packaging)
- 1 pair of brake pads
- 1 pair of mounting bolts
- 1 transport lock
- The brake hose is filled and pre-assembled on the brake calliper!
Clamp, brake disc, adapter, olive and insert pin not included!
For matching brake disc >CLICK HERE<
For suitable adapter >CLICK HERE<
Technologies
Bleeding Edge
The Bleeding Edge™ technology enables quick and easy bleeding of the brakes. Thanks to the new fluid channel and the redesigned bleed port, the fluid can be pumped through the brake caliper more easily. A special adapter can be fitted to the bleed port and seals the system to prevent air ingress and fluid loss.
Expandable bladder
SRAM's new brake lever design includes a new bladder shape that can be used to regulate and reduce air bubbles. The bladder is specially shaped to pump air out of the lever and transport the fluid exactly where it is needed. The result is improved back pressure relief for reliable and consistent braking performance.
PiggyBack™ reservoir
The brake fluid reservoir on SRAM's latest lever design is optimised for performance and ease of use. The PiggyBack™ reservoir offers a simple and safe solution for controlling brake fluid and also allows the levers to be mounted on both sides - so you can swap your levers on the handlebars and brake as easily as on a motorbike.
Twist grip bearing
Sealed precision bearings on the twist grip ensure clean, precise grip movement and enable smooth operation with just one finger.
TPC Plus™ (Timing Port Closure)
The synchronisation port of a hydraulic brake is the connection between the reservoir and the master cylinder bore. When the lever is actuated, a cup seal passes through this area and closes the port, pressurising the system. SRAM's new TPC Plus™ sync port closure system features durable seals and an ultra-soft cylinder bore surface for reliable and consistent braking performance.
DirectLink™
SRAM's DirectLink™ lever design provides a solid, positive braking feel as soon as the brake lever is pulled - a no-compromise solution for precise control.
DOT 5.1™
Heat is the enemy of every braking system. Better heat management also makes your ride much safer. We've found that DOT 5.1 takes three times longer to reach boiling point than DOT 4. This ensures smooth and uninterrupted braking power in even more extreme conditions.
- Manufacturer number: 92.5020.707.270
1000 W Fulton Market 4th Floor
60607 Chigago (Illinois)
United States
Paasbosweg 14
3862 ZS Nijkerk
Netherlands
[email protected]
https://www.sram.com
