Shimano DURA ACE Di2 ST-R9180+BR-R9270 Disc Brake rear
Item no:
20098360
Product information "DURA ACE Di2 ST-R9180+BR-R9270 Disc Brake rear"
The Shimano Dura Ace Di2 ST-R9180 shift/brake lever with BR-R9270 brake caliper for triathlon / time trial. Provides a dosage and control that is second to none. Wireless shifting provides a clean look on the bike and allows uniquely fast and precise shifting.
The hydraulic 2-piston brake caliper BR-R9270 for with Flat-Mount and L03A Resin disc pads with fin. The completely newly developed hydraulic disc brakes provide an unprecedented combination of braking power and controllability. With the brand new monobloc design, the peak of high braking performance has now been reached. The lighter BR-R9270 caliper offers wider pad spacing and reduces noise levels. Finally, a new bleeding system makes maintenance easier than ever before.
E-Tube
Time trial bikes with disc brake: Shimano Dura Ace Di2 ST-R9180 + BR-R9270
Overcoming the sometimes complicated cable routing of time trial and triathlon bikes, the DURA-ACE ST-R9180 levers bring the confidence of hydraulic disc brakes to the sleekest bikes in the world. Combined with the plug and play ease of SHIMANO DI2 electronic shifting, they offer an advantage in any race.The hydraulic 2-piston brake caliper BR-R9270 for with Flat-Mount and L03A Resin disc pads with fin. The completely newly developed hydraulic disc brakes provide an unprecedented combination of braking power and controllability. With the brand new monobloc design, the peak of high braking performance has now been reached. The lighter BR-R9270 caliper offers wider pad spacing and reduces noise levels. Finally, a new bleeding system makes maintenance easier than ever before.
Features - Shimano DURA ACE Di2 ST-R9180 + BR-R9270 hydraulic Disc Brake rear
- Optimum power transmitted with firm grip
- More aerodynamic and better grip feeling
- Switch button integrated inside without hand release
- Intuitive shifting control
- Keep firm grip when shifting
- Single button on each side of the shifting lever only works with SHIMANO SYNCHRONIZED SHIFT
- Better control and confidence in race conditions
- Customizable function to fit in rider’s riding style
- Each switch has the option for multi-shift ON or OFF
- E-TUBE PROJECT
- Clean cockpit area
- Integrated E-TUBE cable and internal brake cable routing
- New cable junction (EW-RS910, EW-JC130) available to integrated with bike frame
Product features
- Use: Triathlon/TT
- Group: Dura Ace Di2
- Model: ST-R9180-R
- Type: Dual-Control-Lever
- Handlebar mounting: DH Bar right
- Gear rear: 11/12-speed
- Optical gear display: No
- Lever reach adjust: Yes
- Clamp band inner diameter: 19.0-22.5mm
- Brake-type: Hydraulic Disc Brake
- Brake caliper: BR-R9270
- Brake mounting: Flat-Mount
- Brake pads: L03A Resin with Fin
- Brake hose: SM-BH90-JK-SSR rear 1700mm (shortable)
- One-Way bleeding: Yes
- Brake fluid: Mineral oil
- Recommended brake rotor: SM-RT900 (140mm/160mm)
- Compatible electric wire: EW-SD50
- E-tube Project: Yes
- E-tube port (pcs): 1
Material
- Body: CFRP
- Lever: Carbon, painted
- Caliper: Aluminium
Color
- Series color
Scope of delivery
- 1 x Shimano Dura Ace Di2 ST-R9180 STI Dual Control Lever right
- 1 x Shimano Dura Ace BR-R9270 Flat-Mount Disc Brake Caliper
- 1 x Brake Pads L03A-Resin with Fin
- 1 x Brake Hose SM-BH90-JK-SSR 1700mm (shortable)
- 2 x Screw for brake caliper 38mm
- 1 x Tube Joint Kit
- J-Kit - The brake hose SM-BH90-JK-SSR is with mineraloil filled and pre-mountedon the caliper BR-R9270!
Disc Rotor SM-RT900 Center-Lock not included!
Technologies
SEIS SHIMANO ELECTRONIC INTELLIGENT SYSTEMThe SEIS innovative shift technology is still based on the SHIMANO INDEX SYSTEM (SIS) that has proved its superior gear changing characteristics over the years. The big difference is that in this case, the shifting action is provided for by electronics instead of mechanics. This electronic shifting system has been extensively tested over past two years by several professional riders in all conditions possible, such as rain, mud, low temperatures, cobble stone roads and combinations of all of these at the same time. Shifting is executed by simply pressing the button. No power is needed to shift, which gives important advantages since it is easier now to always keep a tight grip on the handlebar and to keep your concentration on riding instead on shifting. The shift system allows accurate and effortless shifting in difficult circumstances like when you have cold hands or when you are completely exhausted. Furthermore, the shifting performance will never be affected by contaminated or stretched cables since the shifting signal is transferred electronically. The operating buttons work similarly to mechanical Dual Control Levers so you don’t need to re-program your mind for a new system.
E-Tube
E-Tube platform offers optimum flexibility on your bike. E-TUBE transmits interactive signals and power supply to each parts by “Plug & play” connection. E-TUBE is no rust, no stretch, no freeze and it ensures advanced low maintenance. And SM-PCE1 connects between PC and components to update firmware. Digital device stay the latest version with updating firmware for improve function.
- Manufacturer number: IR91802DRRDSC170
- EAN: 4550170900212
- UPC: 192790900216
Manufacturer:
SHIMANO INC.3-77 Oimatsu-cho, Sakai-ku, Sakai-shi
590-8577 Osaka
Japan
https://www.shimano.com
Person responsible in the EU:
Shimano Europe BVHigh Tech Campus 92
NL-5656 Eindhoven
Netherlands
[email protected]
https://www.shimano.com
