Mondraker ARID CARBON R Superblack
Product information "ARID CARBON R Superblack"
The Mondraker ARID CARBON R is a fast and versatile gravel bike designed for racing, long distances and challenging adventures. The high-quality Stealth Air Carbon frame, offering up to 50 mm of tyre clearance, is complemented by a lightweight Stealth Air Carbon fork. Power is delivered by the SRAM GX Eagle AXS electronic groupset and a SRAM RivalXPLR AXS carbon crankset. Mavic Allroad S Carbon wheels, SRAM Rival AXS HRD disc brakes and carbon components from ONOFF round off the high-quality spec.
Limitless potential. Gravel redefined – the ARID CARBON R from Mondraker
The ARID was born out of a clear conviction: to build a bike that goes anywhere, tackles anything and is fast to boot – simply for the joy of riding. Not a race bike that merely tolerates adventure. Not an adventure bike that merely tolerates racing. A bike that can truly do both, without compromise and without making excuses.
There’s one thing you need to know: this is all about speed
It always has been. Speed is part of its DNA – and we mean that seriously. That’s why the ARID was conceived as a particularly versatile gravel bike and engineered precisely to deliver where it matters most. It’s hard to describe this bike fully in words. So the results speak for themselves: the ARID has proven itself in some of the world’s toughest and most prestigious gravel races and met the highest expectations – from a podium finish at The Traka 2026, through the challenging gravel roads of Emporia at Unbound, right to the desert-like climbs of the Badlands.
Features – Mondraker ARID CARBON R
- High-quality Arid Stealth Air carbon frame with frame storage compartment, internal cable routing, UDH derailleur hanger, 50 mm tyre clearance
- High-quality Stealth Air carbon fork
- SRAM GX Eagle AXS electronic rear derailleur and SRAM Rival XPLR AXS crankset
- Hydraulic SRAM Rival AXS HRD disc brakes with 160 mm CentreLock rotors
- ONOFF S9 GR carbon handlebars and carbon seatpost
- Mavic Allroad S Carbon wheelset
- Maxxis Reaver 45 mm wide tyres
Recommended frame sizes
Highlights
Unlimited versatility.
The ARID Carbon was designed as a multi-purpose tool: a bike that, despite its racing looks, impresses with an extremely comfortable, smooth-riding design and relaxed geometry. It inspires confidence even over hours of riding on varied terrain.
Not just off-road, but on any road, any surface, any distance and to any destination.
Unlimited riding quality.
The ARID Carbon combines a high level of riding comfort with a direct feel and is designed for long distances on a wide variety of surfaces.
Optimised Stealth Air Carbon fork.
Less is more. The redesigned Stealth Air Carbon fork does away with the side mounting points, giving it a sleeker silhouette and making it around 20 grams lighter.
Cleaner lines, reduced weight and targeted flex ensure vertical compliance and a direct riding feel exactly where it matters most.
A detail that isn’t immediately obvious, but becomes clearly noticeable after hours in the saddle.
Up to 50 mm of tyre clearance.
The ARID Carbon accommodates tyres up to 50 mm wide without any additional adjustments. In a category where many top competitors reach their limit at 42 mm or less, this difference makes itself felt exactly where it counts most: in the mud at Unbound, on the rocks at The Traka, or on challenging roads and trails.
The trend towards wider gravel tyres offers more options in terms of grip, comfort and control – and the ARID Carbon is designed with this in mind.
Unrestricted handling.
A balanced geometry and components tailored to each frame size ensure precise handling and a natural riding position.
Frame-size-specific handlebar widths.
The handlebar widths are precisely matched to the respective frame size:
S: 400 mm
M and M/L: 420 mm
L: 440 mm
XL: 460 mm
The result is a more natural riding position with improved handling precision and reduced fatigue in the arms and shoulders on long days in the saddle. The right reach and the right control in every size.
Endless adventures.
The ARID Carbon is designed for long distances and versatile gravel adventures, offering well-thought-out solutions built right into the bike.
Improved carry-on storage compartment.
The integrated in-frame storage compartment, a key feature of the ARID Carbon, has been significantly improved for 2027. The revised design allows for easier access and simpler removal of the bags. Tools, food and other essential items are therefore quick and easy to reach. Tidy, intuitive and designed for long distances.
Please note that pedals are not included!
- Manufacturer number: 010.27112BK
- Model Year: 2027
Elche Parque Empresarial C/ Juan de la Cierva 62
3203 Elche (Alicante)
Spain
[email protected]
http://https://www.mondraker.com
Mondraker ARID CARBON R Superblack
The Mondraker ARID CARBON R is a fast and versatile gravel bike designed for racing, long distances and challenging adventures. The high-quality Stealth Air Carbon frame, offering up to 50 mm of tyre clearance, is complemented by a lightweight Stealth Air Carbon fork. Power is delivered by the SRAM GX Eagle AXS electronic groupset and a SRAM RivalXPLR AXS carbon crankset. Mavic Allroad S Carbon wheels, SRAM Rival AXS HRD disc brakes and carbon components from ONOFF round off the high-quality spec.
Limitless potential. Gravel redefined – the ARID CARBON R from Mondraker
The ARID was born out of a clear conviction: to build a bike that goes anywhere, tackles anything and is fast to boot – simply for the joy of riding. Not a race bike that merely tolerates adventure. Not an adventure bike that merely tolerates racing. A bike that can truly do both, without compromise and without making excuses.
There’s one thing you need to know: this is all about speed
It always has been. Speed is part of its DNA – and we mean that seriously. That’s why the ARID was conceived as a particularly versatile gravel bike and engineered precisely to deliver where it matters most. It’s hard to describe this bike fully in words. So the results speak for themselves: the ARID has proven itself in some of the world’s toughest and most prestigious gravel races and met the highest expectations – from a podium finish at The Traka 2026, through the challenging gravel roads of Emporia at Unbound, right to the desert-like climbs of the Badlands.
Features – Mondraker ARID CARBON R
- High-quality Arid Stealth Air carbon frame with frame storage compartment, internal cable routing, UDH derailleur hanger, 50 mm tyre clearance
- High-quality Stealth Air carbon fork
- SRAM GX Eagle AXS electronic rear derailleur and SRAM Rival XPLR AXS crankset
- Hydraulic SRAM Rival AXS HRD disc brakes with 160 mm CentreLock rotors
- ONOFF S9 GR carbon handlebars and carbon seatpost
- Mavic Allroad S Carbon wheelset
- Maxxis Reaver 45 mm wide tyres
Recommended frame sizes
Highlights
Unlimited versatility.
The ARID Carbon was designed as a multi-purpose tool: a bike that, despite its racing looks, impresses with an extremely comfortable, smooth-riding design and relaxed geometry. It inspires confidence even over hours of riding on varied terrain.
Not just off-road, but on any road, any surface, any distance and to any destination.
Unlimited riding quality.
The ARID Carbon combines a high level of riding comfort with a direct feel and is designed for long distances on a wide variety of surfaces.
Optimised Stealth Air Carbon fork.
Less is more. The redesigned Stealth Air Carbon fork does away with the side mounting points, giving it a sleeker silhouette and making it around 20 grams lighter.
Cleaner lines, reduced weight and targeted flex ensure vertical compliance and a direct riding feel exactly where it matters most.
A detail that isn’t immediately obvious, but becomes clearly noticeable after hours in the saddle.
Up to 50 mm of tyre clearance.
The ARID Carbon accommodates tyres up to 50 mm wide without any additional adjustments. In a category where many top competitors reach their limit at 42 mm or less, this difference makes itself felt exactly where it counts most: in the mud at Unbound, on the rocks at The Traka, or on challenging roads and trails.
The trend towards wider gravel tyres offers more options in terms of grip, comfort and control – and the ARID Carbon is designed with this in mind.
Unrestricted handling.
A balanced geometry and components tailored to each frame size ensure precise handling and a natural riding position.
Frame-size-specific handlebar widths.
The handlebar widths are precisely matched to the respective frame size:
S: 400 mm
M and M/L: 420 mm
L: 440 mm
XL: 460 mm
The result is a more natural riding position with improved handling precision and reduced fatigue in the arms and shoulders on long days in the saddle. The right reach and the right control in every size.
Endless adventures.
The ARID Carbon is designed for long distances and versatile gravel adventures, offering well-thought-out solutions built right into the bike.
Improved carry-on storage compartment.
The integrated in-frame storage compartment, a key feature of the ARID Carbon, has been significantly improved for 2027. The revised design allows for easier access and simpler removal of the bags. Tools, food and other essential items are therefore quick and easy to reach. Tidy, intuitive and designed for long distances.
Please note that pedals are not included!
- Manufacturer number: 010.27112BK
- Model Year: 2027
Elche Parque Empresarial C/ Juan de la Cierva 62
3203 Elche (Alicante)
Spain
[email protected]
http://https://www.mondraker.com
Configuration
| Frame: | Arid Stealth Air Carbon, in-tube storage, T47 bottom bracket, tapered head tube, HHG internal cable routing, 12x142mm rear axle, UDH, 1X drivetrain design, Flatmount brake compatible. |
|---|---|
| Frame material: | Carbon |
| Wheel size: | 28" |
| Speeds: | 1x12 |
| Fork: | Steatlh Air Carbon tapered steerer tube, HHG, fllat mount integrated fork |
| Brakes: | Sram Rival AXS HRD 2 piece caliper, Paceline |
| Brake discs: | 160mm / 160mm Centerlock rotor, steel-backed organic pad |
| Brake levers: | Sram Rival, tooled reach adjust, carbon brake lever |
| Colour: | Superblack |
| Headset: | Onoff IS52/IS52, 1-1/8", 1.5" head tube, sealed bearings, Internal cable routing |
| Stem: | Onoff Semi-Integrated, 31.8mm barbore, rise: -7°, length: S size: 60mm, M size: 70mm, ML size 70mm, L size: 80mm, XL size: 90mm |
| Handlebar: | Onoff S9 GR Carbon 16º bar flare. Width sizes S size: 400mm M size: 420mm ML size: 420mm L size: 440mm XL size: 460mm |
| Handlebar tape: | Fizik Terra Solocush Tacky Bartape |
| Saddle: | Fizik Vento Argo X5 140mm |
| Seatpost: | Onoff S9 Carbon 15-R, diameter 27.2mm, length: S size: 400mm, M size: 400mm, ML size 400mm, L size: 450m, XL size: 450mm |
|---|---|
| Crankset: | Sram Rival XPLR, DUB WIDE axle, S size: 165mm M size: 165mm ML size: 170mm L size: 172,5mm XL size: 172,5mm, CL 47,5, Sram 40T Direct mount, alloy, narrow-wide, |
| Bottom bracket: | Sram DUB T47 BSA, sealed bearings, 85,5mm |
| Rear derailleur: | Sram GX Eagle AXS T-Type,12s |
| Gear shifters: | Sram Rival AXS HRD |
| Cassette: | Sram XS-1275, 10-52T, T-Type, 12s |
| Chain: | Sram GX Eagle T-Type, 12s Flattop, Powerlock |
| Tyres: | Maxxis Reaver 700x45, HYPR-X compound, EXO protection, tubeless ready, 120 TPI, folding bead |
| Front hub: | Mavic, 12x100mm, Centerlock |
| Rear hub: | Mavic infinity hub, 12x142mm, ID360 Ratchet system, Centerlock, XDR Freehub |
| Spokes : | Mavic Steel J Bent spokes |
| Rims: | Mavic Allroad S Carbon, UST,42mm height, 25mm internal width, 24 spokes |
| Maximum total weight allowed: | 115 kg (body weight + bicycle + kit) |
| Weight: | 9.3 kg |
Geometry
