Flyer G1 Uproc X 2.10 FS
%
Product information "G1 Uproc X 2.10 FS"
Concentrated power and huge energy reserves: the Flyer Uproc X pushes the boundaries in the mountains and on trails. With perfectly tuned 150 mm suspension and balanced geometry of the carbon frame, it shines on the climbs as well as on the descents. This super-strong, full-suspension e-bike is always ready to explore new territory. It is a robust e-bike with a carbon frame, powerful Panasonic GX Ultimate Pro FIT motor with 95 Nm torque and a good range thanks to the powerful battery (630 Wh). Equipped with a Shimano Deo 1x11 gearshift, hydraulic 4-piston disc brakes and suspension elements for good performance. The integrated MonkeyLink interface makes it easy to connect a front light, which is powered by the e-bike battery.
Features - Flyer G1 Uproc X 2.10 FS
- A robust carbon frame with internal cable routing and an integrated speed sensor (Mullet: 29" front, 27.5" rear)
- Powerful Panasonic GX Ultimate Pro FIT motor with 95Nm torque, push assist and 4 support levels
- Long range, thanks to a high-capacity battery (630 Wh)
- FIT Remote DSP1-S 1.3-inch color display – clear and intuitive control of the e-bike system
- RockShox 35 Silver suspension fork with 150 mm travel and RockShox Deluxe Select shock
- Shimano 1x11-speed gear system
- Shimano hydraulic 4-piston disc brakes with 203 mm brake discs
- Alexrims MD30 wheelset with Formula hubs, DT Swiss spokes and Onza Porcupine tyres
- Compatible with “MonkeyLink Connect”
The ultra-quiet ‘Panasonic GX Ultimate Pro FIT’ motor delivers powerful assistance with 95 Nm of torque and 600 watts of peak power. The bolt-on battery mount guarantees that the fully integrated battery is held absolutely securely and vibration-free, whilst also allowing it to be swapped in just a few simple steps – even whilst out on the trail. The powerful motor and a maximum rider weight of 140 kg ensure a smooth, stable ride. Well-thought-out details such as internally routed cables and the speed sensor integrated into the frame create a clean, uncluttered look and emphasise the bike’s premium character.
Recommended frame sizes
| S | M | L | XL |
|---|---|---|---|
| 155–165 cm | 165–175 cm | 175–185 cm | 185–195 cm |
Panasonic GX Ultimate e-bike motor
- Manufacturer number: 173003
- Model Year: 2024
Manufacturer:
FLYER AGSchwende 1
4950 Huttwil
Switzerland
www.flyer-bikes.com/de-ch/contact
Person responsible in the EU:
FLYER Bikes Austria GmbHAignerstraße 32
5026 Salzburg
www.flyer-bikes.com/contact
Flyer G1 Uproc X 2.10 FS
Concentrated power and huge energy reserves: the Flyer Uproc X pushes the boundaries in the mountains and on trails. With perfectly tuned 150 mm suspension and balanced geometry of the carbon frame, it shines on the climbs as well as on the descents. This super-strong, full-suspension e-bike is always ready to explore new territory. It is a robust e-bike with a carbon frame, powerful Panasonic GX Ultimate Pro FIT motor with 95 Nm torque and a good range thanks to the powerful battery (630 Wh). Equipped with a Shimano Deo 1x11 gearshift, hydraulic 4-piston disc brakes and suspension elements for good performance. The integrated MonkeyLink interface makes it easy to connect a front light, which is powered by the e-bike battery.
Features - Flyer G1 Uproc X 2.10 FS
- A robust carbon frame with internal cable routing and an integrated speed sensor (Mullet: 29" front, 27.5" rear)
- Powerful Panasonic GX Ultimate Pro FIT motor with 95Nm torque, push assist and 4 support levels
- Long range, thanks to a high-capacity battery (630 Wh)
- FIT Remote DSP1-S 1.3-inch color display – clear and intuitive control of the e-bike system
- RockShox 35 Silver suspension fork with 150 mm travel and RockShox Deluxe Select shock
- Shimano 1x11-speed gear system
- Shimano hydraulic 4-piston disc brakes with 203 mm brake discs
- Alexrims MD30 wheelset with Formula hubs, DT Swiss spokes and Onza Porcupine tyres
- Compatible with “MonkeyLink Connect”
The ultra-quiet ‘Panasonic GX Ultimate Pro FIT’ motor delivers powerful assistance with 95 Nm of torque and 600 watts of peak power. The bolt-on battery mount guarantees that the fully integrated battery is held absolutely securely and vibration-free, whilst also allowing it to be swapped in just a few simple steps – even whilst out on the trail. The powerful motor and a maximum rider weight of 140 kg ensure a smooth, stable ride. Well-thought-out details such as internally routed cables and the speed sensor integrated into the frame create a clean, uncluttered look and emphasise the bike’s premium character.
Recommended frame sizes
| S | M | L | XL |
|---|---|---|---|
| 155–165 cm | 165–175 cm | 175–185 cm | 185–195 cm |
Panasonic GX Ultimate e-bike motor
- Manufacturer number: 173003
- Model Year: 2024
Manufacturer:
FLYER AGSchwende 1
4950 Huttwil
Switzerland
www.flyer-bikes.com/de-ch/contact
Person responsible in the EU:
FLYER Bikes Austria GmbHAignerstraße 32
5026 Salzburg
www.flyer-bikes.com/contact
Configuration
| Frame: | Engineered by FLYER, internal cable routing, 4-link suspension, 140 mm, 12 × 148 mm |
|---|---|
| Frame material: | Carbon |
| Wheel size: | Mullet Front: 29" Rear 27.5" |
| Speeds: | 1 x 11 |
| Colour: | Black Shading Satin |
| Fork: | RockShox 35 Silver TK Solo Air, 150 mm Travel, 15 x 110 mm |
| Rear Shock: | RockShox Deluxe Select, 230 x 60 mm |
| Travel: | 150mm / 150mm |
| Brakes: | Shimano BR-MT420, 4 piston |
| Brake discs: | Shimano SLX RT66, 203 mm |
| Brake levers: | Shimano BL-M4100 |
| Headset: | Acros AIF-558 HT60 w/o Star |
| Stem: | Satori Ursa, 35 × 35 mm, 0° |
| Handlebar: | Ergotec Ergo XXL, 700 mm, 16°, 30 mm |
| Bar grips: | VPG-122A |
| Saddle: | Selle Royal Vivo |
| Seatpost: | FLYER Dropper Post MT214, 34.9 mm, Travel: S 125mm, M 150mm, L 170mm, XL 170mm |
| Seat clamp: | FLYER UR6, 34.9 mm |
| Crankset: | Samox EC40 |
| Rear derailleur: | SHIMANO Deore, 11 Gang, 11-51t |
|---|---|
| Gear shifters: | Shimano Deore SL-M5100, 11 speed |
| Cassette: | Shimano Deore CS-M5100, 11 speed, 11-51t |
| Chain: | SHIMANO HG 601 11S |
| Front tyre: | Onza Porcupine TRC, 29 x 2,40", 61-622 |
| Rear tyre: | Onza Porcupine TRC, 27,5 x 2,60", 66-584 |
| Front hub: | Formula DC-511, 32h |
| Rear hub: | Formula EHL-148S, 32h |
| Spokes : | Front: DT SWISS Champion 2.0 x 292/290 mm / Rear: DT SWISS Champion 2.0 x 274/272mm |
| Rims: | Alexrims MD30, 30 mm |
| Display: | FIT Remote Display DSP1-S (1,3" color display) |
| Battery: | FLYER FIB 630 36 V FIT (630 Wh / 17.5 Ah / 36 V) |
| Charger: | FIT Fast Charger 36 V 4 A |
| Engine: | Panasonic GX Ultimate Pro FIT, 95 Nm / 25 km/h, Support steps: Support levels: ECO (70%), STANDART (150%), HIGH (300%), AUTO (70-300%), Pushing aid: Yes |
| Front light: | MonkeyLink Connect ready |
| Backlight: | MonkeyLink Recharge ready |
| Pedals: | VP 532 |
| Maximum total weight allowed: | 140 kg (body weight + bicycle + equipment) |
| Weight: | ab 26 kg |
Geometry
460 mm
435 mm
77 °
400 mm
612 mm
772 mm
64.5 °
102 mm
567 mm
1221 mm
