Cube Editor SLX FE ammolite'n'reflex Trapeze
Product information "Editor SLX FE ammolite'n'reflex Trapeze"
Open 360° viewHighlights
- Elegant aluminium frame with internal cable routing, designed for a maximum system weight of 140 kg
- CUBE TK Disc C:62 carbon rigid fork
- Shimano Alfine SG-S7001 11-speed internal gear hub, combined with Gates belt drive
- Hydraulic Shimano RS600/405 disc brakes with 160 mm rotors
- Fast-rolling and comfortable 55 mm Schwalbe Motion Big Apple tires
- Equipped with mudguards, lighting system and kickstand
FRAME Cube Editor SLX FE amoolite´n´reflex trapeze
City life can be demanding, so the Editor FE comes fully equipped for any journey with Cubes Semi Integrated Carrier 2.0, full-length mudguards, a kickstand and a dynamo-powered lighting set. Designed around the low maintenance of a clean, quiet belt drive, the lightweight double-butted aluminium frame – in a familiar Trapeze format – features carefully crafted tube joints for an almost seamless, organic appearance. Fully integrated cable routing complements the pared-back aesthetic, and the light and svelte C:62® carbon fork is the perfect accompaniment. It's everything you need to thrive in the city.
Technologie
Urban Geometry
City streets are the natural home of our urban bikes, so we gave them geometry to match. Nimble for weaving safely through traffic, with ideal weight distribution for great grip and safe braking and cornering, Urban Geometry is precisely what you need to help you navigate the mean streets safely... and beat the gridlock.
Fully Equipped
A bicycle is such a versatile tool. That's why many riders add accessories like a luggage carrier, mudguards, kickstand and lights. But with our Fully Equipped range you don't have to, because we've already taken care of all of that. With carefully selected accessories that match and integrate with each bike, you're all set for any journey from the weekday commute to a longer tour.
Internal Cable Routing
Cables connect your handlebar controls to vital components like gears and brakes, but there's no need for them to get in your way. With Internal Cable Routing we've reduced clutter and maintenance by running cables through the frame, keeping them out of the way of dust and water contamination – or damage from abrasion – as well as cleaning up your bike's appearance.
Aluminium Superlite
CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.
- Manufacturer number: 155411
- Model Year: 2026
Ludwig-Hüttner-Str. 5-7
95679 Waldershof
Deutschland
https://www.cube.eu/kontakt
Cube Editor SLX FE ammolite'n'reflex Trapeze
Open 360° viewHighlights
- Elegant aluminium frame with internal cable routing, designed for a maximum system weight of 140 kg
- CUBE TK Disc C:62 carbon rigid fork
- Shimano Alfine SG-S7001 11-speed internal gear hub, combined with Gates belt drive
- Hydraulic Shimano RS600/405 disc brakes with 160 mm rotors
- Fast-rolling and comfortable 55 mm Schwalbe Motion Big Apple tires
- Equipped with mudguards, lighting system and kickstand
FRAME Cube Editor SLX FE amoolite´n´reflex trapeze
City life can be demanding, so the Editor FE comes fully equipped for any journey with Cubes Semi Integrated Carrier 2.0, full-length mudguards, a kickstand and a dynamo-powered lighting set. Designed around the low maintenance of a clean, quiet belt drive, the lightweight double-butted aluminium frame – in a familiar Trapeze format – features carefully crafted tube joints for an almost seamless, organic appearance. Fully integrated cable routing complements the pared-back aesthetic, and the light and svelte C:62® carbon fork is the perfect accompaniment. It's everything you need to thrive in the city.
Technologie
Urban Geometry
City streets are the natural home of our urban bikes, so we gave them geometry to match. Nimble for weaving safely through traffic, with ideal weight distribution for great grip and safe braking and cornering, Urban Geometry is precisely what you need to help you navigate the mean streets safely... and beat the gridlock.
Fully Equipped
A bicycle is such a versatile tool. That's why many riders add accessories like a luggage carrier, mudguards, kickstand and lights. But with our Fully Equipped range you don't have to, because we've already taken care of all of that. With carefully selected accessories that match and integrate with each bike, you're all set for any journey from the weekday commute to a longer tour.
Internal Cable Routing
Cables connect your handlebar controls to vital components like gears and brakes, but there's no need for them to get in your way. With Internal Cable Routing we've reduced clutter and maintenance by running cables through the frame, keeping them out of the way of dust and water contamination – or damage from abrasion – as well as cleaning up your bike's appearance.
Aluminium Superlite
CUBE's Aluminium Superlite starts with heat-treated 6061 aluminium, which has the qualities – high fatigue resistance, good stiffness, low weight and excellent strength – that are important for a bicycle frame. Then we make it into double butted tubes, to reduce weight without sacrificing any of its strength. The result? Exceptionally light, strong and tough frames.
- Manufacturer number: 155411
- Model Year: 2026
Ludwig-Hüttner-Str. 5-7
95679 Waldershof
Deutschland
https://www.cube.eu/kontakt
Configuration
| Frame: | Aluminium Superlite, Urban 29, Taper, Double Butted |
|---|---|
| Frame material: | aluminium |
| Wheel size: | 28" |
| Speeds: | 1 x 11 |
| Colour: | amoolite´n´reflex |
| Fork: | CUBE TK Disc, C:62® Full Carbon, Taper, Flat Mount, 12x100mm |
| Brakes: | Shimano BL-RS600/405, Hydr. Disc Brake, FM (160) |
| Brake discs: | 160/160 mm |
| Headset: | ACROS AZF-1035, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2 (ZS 56mm), Botttom Zero-Stack 1 1/2 |
| Stem: | CUBE Performance Stem SLX, FPI-Link, 31.8mm |
| Handlebar: | CUBE Comfort Trail Bar, 680mm |
| Bar grips: | ACID Travel |
| Saddle: | Natural Fit Sequence |
| Seatpost: | CUBE Performance Post, 27.2mm |
| Crankset: | Gates S150 CDN, 46T, 45.5mm Beltline |
|---|---|
| Gear shifters: | Shimano Alfine SL-S700 |
| Tyres: | Schwalbe Motion Big Apple, PerfL, 55-622 |
| Front hub: | ACID PL-7, Hub Dynamo, 12x100, Centerlock |
| Rear hub: | Shimano Alfine SG-S7001, 11-Speed |
| Rims: | ACID EX25, 32H, Disc, Tubeless Ready |
| Front light: | ACID Pro-D 100 |
| Backlight: | ACID Pro-D SIC 2.0 |
| Rack: | ACID SIC 2.0 RILink |
| Pedals: | not included |
| Other details: | Knog Oi |
| Maximum total weight allowed: | 140 kg (body weight + bike + equipment) |
| Weight: | ab 14.8 kg |
